4-68 Centrifugal blower
The 4-68 centrifugal blower is a meritorious product in the history of China’s blower industry. With its high efficiency, energy saving, low noise and stability, it has provided reliable ventilation solutions for many industrial and life fields in the past few decades. Although more new models and high-efficiency blowers have appeared, 4-68 blowers still play an important role in many occasions because of their mature technology, controllable cost and convenient maintenance.
Specifications:
Pressure range: 720–6531 Pa
Air volume: 1966–194495 m³/h
Power: 15 kW–1600 kW
Drive type: Direct drive / Coupling drive / Belt drive
Cooling method: Water cooling / Oil cooling (optional)
CONFIGURATION OPTIONS
1. CONSTRUCTION & MATERIALS
Impeller: Carbon steel; optional materials include FRP, stainless steel, rubber lining, wear-resistant coating, or ceramic coating.
Casing/Volute: Standard material is carbon steel; optional materials include FRP or stainless steel.
Main shaft: High-strength alloy steel.
Bearings: ZWZ / SKF / FAG / NSK.
2.SYSTEM & ACCESSORIES
-
Motor: High-efficiency Chinese brand or ABB / Siemens / WEG.
-
Optional Parts: Base frame, silencer, flexible joint, damper, rain cover, shock absorber, sensors, inverter, soft starter, monitoring instruments.
| Serial number | Machine number No | Rotating Speed (r/min) | Full Pressure (Pa) | Air Volume (m³/h) | Power (kW) |
|---|---|---|---|---|---|
| 1 | 2.8A | 2900 | 970~657 | 1131~2262 | 1.1 |
| 1 | 2.8A | 1450 | 245~166 | 565~1131 | 0.55 |
| 2 | 3.15A | 2900 | 1245~853 | 1825~3435 | 1.5 |
| 2 | 3.15A | 1450 | 313~215 | 912~1718 | 0.55 |
| 3 | 3.55A | 2900 | 1608~1108 | 2708~5013 | 3.0 |
| 3 | 3.55A | 1450 | 402~274 | 1354~2507 | 0.55 |
| 4 | 4A | 2900 | 2069~1431 | 3984~7281 | 4.0 |
| 4 | 4A | 1450 | 519~353 | 1992~3641 | 0.75 |
| 5 | 4.5A | 2900 | 2657~1833 | 5790~10485 | 7.5 |
| 5 | 4.5A | 1450 | 666~460 | 2895~5242 | 1.1 |
| 6 | 5A | 2900 | 3314~2304 | 8050~14490 | 15.0 |
| 6 | 5A | 1450 | 823~578 | 4025~7245 | 2.2 |
| 7 | 6.3D | 1450 | 1323~921 | 8320~14761 | 5.5 |
| 7 | 6.3D | 960 | 578~402 | 5508~9773 | 2.2 |
| 8 | 8D | 1450 | 2157~1500 | 17585~30774 | 18.5 |
| 8 | 8D | 960 | 941~657 | 11643~20375 | 5.5 |
| 8 | 8D | 730 | 549~382 | 8853~15403 | 3.0 |
| 9 | 10D | 1450 | 3442~2422 | 35420~61179 | 55.0 |
| 9 | 10D | 960 | 1510~1059 | 23450~40505 | 18.5 |
| 9 | 10D | 730 | 872~617 | 17832~30801 | 7.5 |
| 10 | 12.5D | 960 | 2353~1657 | 45800~79111 | 55.0 |
| 10 | 12.5D | 730 | 1363~961 | 34828~60157 | 22.0 |
| 11 | 6.3C | 2240 | 3159~2196 | 12852~22803 | 22.0 |
| 11 | 6.3C | 2000 | 2510~1755 | 11476~20359 | 15.0 |
| 11 | 6.3C | 1800 | 2040~1422 | 10328~18324 | 11.0 |
| 11 | 6.3C | 1600 | 1608~1117 | 9180~16287 | 7.5 |
| 11 | 6.3C | 1400 | 1235~863 | 8032~14251 | 5.5 |
| 11 | 6.3C | 1250 | 980~686 | 7172~12724 | 4.0 |
| 11 | 6.3C | 1120 | 784~549 | 6426~11401 | 3.0 |
| 11 | 6.3C | 1000 | 627~441 | 5737~10179 | 2.2 |
| 11 | 6.3C | 900 | 509~353 | 5164~9162 | 1.5 |
| 11 | 6.3C | 800 | 402~284 | 4590~8144 | 1.1 |
| 12 | 8C | 1800 | 3314~2314 | 21830~38202 | 37.0 |
| 12 | 8C | 1600 | 2618~1833 | 19404~33958 | 30.0 |
| 12 | 8C | 1400 | 2009~1401 | 16799~29713 | 18.5 |
| 12 | 8C | 1250 | 1597~1117 | 15159~26528 | 15.0 |
| 12 | 8C | 1120 | 1284~892 | 13583~23770 | 11.0 |
| 12 | 8C | 1000 | 1019~715 | 12128~21224 | 7.5 |
| 12 | 8C | 900 | 833~578 | 10915~19101 | 5.5 |
| 12 | 8C | 800 | 657~460 | 9702~16979 | 4.0 |
| 12 | 8C | 710 | 519~362 | 8611~15069 | 3.0 |
| 12 | 8C | 630 | 402~284 | 7641~13371 | 2.2 |
